Mobile Visual Regression Without Doubling Your Test Count

A grid of device screens showing the same interface at different sizes
Apr 10, 20262 min readPlaywright, CI/CD, TypeScript

Nine Tests, Copied Twice

I had nine visual regression tests in Playwright, one per page. Each test navigated to a URL, waited for load, and called toHaveScreenshot. They were nearly identical except for three things: the URL, the snapshot name, and a few per-page quirks (the homepage needs a stable-height poll for GSAP animations; the about page masks the hCaptcha widget).

When I needed mobile screenshots at 390×844 alongside the existing 1280×720 desktops, the obvious approach was to duplicate all nine tests with a different viewport. That would have taken me from 9 tests to 18, with every line of navigation and wait logic copied.

The Page Config

Instead of duplicating tests, I described what varies in a typed array:

const pages = [
  {
    name: 'homepage',
    path: '/',
    headingSelector: 'h1',
    maxDiffPixelRatio: 0.05,
    waitForStableHeight: true,
    maskHCaptcha: false,
  },
  {
    name: 'about',
    path: '/about',
    headingSelector: 'h1',
    maxDiffPixelRatio: 0.02,
    waitForStableHeight: false,
    maskHCaptcha: true,
  },
  // ... 7 more entries
] as const;

Each entry captures the decisions that were previously buried in test bodies. The homepage gets a 5% diff threshold because GSAP animations cause layout height variance. The about page masks hCaptcha because the widget loads dynamically. Every other page uses the same 2% threshold with no masks beyond [data-gsap].

Two Helpers, Two Loops

The shared logic lives in two functions. waitForPageReady handles navigation, heading visibility, and the optional stable-height poll:

async function waitForPageReady(page: Page, entry: (typeof pages)[number]) {
  await page.goto(entry.path, { waitUntil: 'domcontentloaded' });
  await page.waitForLoadState('load');

  if (entry.name === 'audit-report-not-found') {
    await page
      .getByRole('heading', { name: 'Report Not Found' })
      .waitFor({ state: 'visible' });
  } else {
    await page
      .locator(entry.headingSelector!)
      .first()
      .waitFor({ state: 'visible' });
  }

  if (entry.waitForStableHeight) {
    await expect
      .poll(
        async () => {
          const h1 = await page.evaluate(() => document.body.scrollHeight);
          await new Promise(r => setTimeout(r, 250));
          const h2 = await page.evaluate(() => document.body.scrollHeight);
          return h1 === h2;
        },
        { timeout: 5000 }
      )
      .toBeTruthy();
  }
}

getMasks builds the locator array from the config flags:

function getMasks(page: Page, entry: (typeof pages)[number]) {
  const masks = [page.locator('[data-gsap]')];
  if (entry.maskHCaptcha) masks.push(page.locator('.min-h-\\[78px\\]'));
  return masks;
}

The test blocks are two test.describe wrappers that loop over the same array at different viewport sizes. The only difference is the beforeEach viewport and the snapshot filename suffix:

test.describe('desktop (1280x720)', () => {
  test.beforeEach(async ({ page }) => {
    await page.setViewportSize({ width: 1280, height: 720 });
  });

  for (const entry of pages) {
    test(`${entry.name} visual regression`, async ({ page }) => {
      await waitForPageReady(page, entry);
      await expect(page).toHaveScreenshot(`${entry.name}.png`, {
        fullPage: true,
        maxDiffPixelRatio: entry.maxDiffPixelRatio,
        mask: getMasks(page, entry),
      });
    });
  }
});

test.describe('mobile (390x844)', () => {
  test.beforeEach(async ({ page }) => {
    await page.setViewportSize({ width: 390, height: 844 });
  });

  for (const entry of pages) {
    test(`${entry.name} mobile visual regression`, async ({ page }) => {
      await waitForPageReady(page, entry);
      await expect(page).toHaveScreenshot(`${entry.name}-mobile.png`, {
        fullPage: true,
        maxDiffPixelRatio: entry.maxDiffPixelRatio,
        mask: getMasks(page, entry),
      });
    });
  }
});

CI Got It for Free

The existing update-snapshots workflow dispatch runs playwright test src/visual-regression.spec.ts --update-snapshots --project=chromium. Because both viewport blocks live in the same spec file, the workflow regenerates desktop and mobile baselines in one pass. No workflow changes needed.

The Takeaway

When tests differ only in data, not in logic, the test itself should be a loop over that data. A nine-element config array gave me 18 visual regression tests across two viewports at 180 lines, down from what would have been 300+ lines of copy-paste. Adding a third viewport, say tablet at 768×1024, is three lines: one test.describe, one setViewportSize, one filename suffix.
