Designing a Mobile Bottom Nav That Plays Nice with FABs and Sheets

The Layering Problem

Adding a fixed bottom navigation bar to a mobile app sounds simple. But this site already had two fixed-position elements at the bottom of the screen: a scroll-to-top FAB on the right and a table-of-contents FAB on the left. Both sat at bottom: 1.5rem and z-index: 50.

Drop a h-14 fixed bottom bar at z-index: 50 and both buttons disappear behind it. Tap where the scroll-to-top button should be and you're hitting the nav bar instead.

The Z-Index Stack

The fix required defining a deliberate stacking order — not just "make it higher." We settled on three layers:

FABs sit below the nav bar. They're secondary actions — you can always scroll to find the content, but you always need the nav. Sheets that slide up from the bottom need to cover the nav bar, so they get z-51.

// ScrollToTop — z-40, raised above nav on mobile
'fixed bottom-20 md:bottom-6 right-6 z-40 ...';

// Bottom nav bar — z-50
'fixed bottom-0 left-0 right-0 z-50 bg-surface/95 ...';

// ToC bottom sheet — z-51, covers nav when open
'fixed bottom-0 left-0 right-0 z-51 bg-surface ...';

The Responsive Escape Hatch

The bottom nav only exists on mobile (md:hidden). Desktop has a traditional sticky top bar. So FABs need different positioning per breakpoint:

className = 'fixed bottom-20 md:bottom-6 right-6 z-40 ...';

bottom-20 (5rem) clears the h-14 (3.5rem) nav bar plus breathing room on mobile. md:bottom-6 restores the original position on desktop where there's no bottom bar. One utility class, no JavaScript.

Reusing the Sheet Pattern

The site already had a bottom sheet for the table of contents — a translate-y transition that slides up from off-screen:

<div
  className={cn(
    'fixed bottom-0 left-0 right-0 z-51 ...',
    isOpen ? 'translate-y-0' : 'translate-y-full pointer-events-none'
  )}
>

The "More" menu in the new bottom nav uses the exact same pattern: translate-y-0 when open, translate-y-full pointer-events-none when closed. Same focus trap hook, same Escape key handler, same body scroll lock. Consistency in animation patterns means users build a mental model once and apply it everywhere.

Accessibility Considerations

A fixed bottom bar introduces several a11y requirements:

• aria-current="page" on the active nav link, not just a color change
• aria-expanded on the More button to communicate sheet state
• aria-modal="true" on the sheet dialog
• Focus trap inside the sheet when open (via useFocusTrap hook)
• Escape key closes the sheet and returns focus to the More button
• Body scroll lock prevents background scrolling while the sheet is open

The More button's label also changes dynamically:

aria-label={sheetOpen ? 'Close more menu' : 'Open more menu'}

The Takeaway

Fixed-position elements are easy to add individually. The complexity is in how they interact. Defining a z-index stack as a deliberate system — not ad-hoc increments — prevents the "just make it higher" escalation that eventually leads to z-index: 9999. Three layers with clear ownership is all this site needs.
